MTC-568 Extra Duty Series
Everything you love about the original Millibar Manual Tool Changer
now scaled for heavier payloads
- Tailored for next-generation robots with extended reach and higher payload capacity
- Provides additional stability for high-speed applications on smaller robots
Fits three larger ISO patterns
The MTC-568 Extra Duty Series Manual Tool Changer comes with holes and hardware to fit 50mm, 63mm, and 80mm tool flange configurations.
No adapter plates required
The robot side connects directly to the robot wrist, with a matching tool side mounted directly to the end effector, one tool side to each EOAT.
Pre-engineered tool sides and blanks
Get a head start by using one of our ready-to-go tool sides for common configurations, or order the blank tool side to do your own machining.
MTC-568-RS
$1,524.75
The MTC-568-RS Extra Duty Series Manual Tool Changer
Everything you love about the original Millibar Manual Tool Changer, now scaled for heavier payloads!
The MTC-568-RS robot side makes changing end of arm tools/ end effectors effortless and fast and without tools. Simply release the locking lever and slide a new tool into place.
- Tailored for next-generation robots with extended reach and higher payload capacity
- Provides additional stability for high-speed applications on smaller robots
The MTC-568 Extra Duty Series Manual Tool Changer comes with holes and hardware to fit 50mm and 80mm tool flange configurations. Alignment with the robot is assured with the included center alignment disks and dowel pins. All mounting hardware is included. No adapter plates are required.
CAD Files
| Format | Download | Notes |
|---|---|---|
| STEP | Download | If you have any difficulty downloading the file, please call us at (508) 488-9870. |
